11-2
Inverter Brakingunit Brakingresistor
Braking
torque
(Peak/
Continues)
10%ED
Minimum
Resistance
*1
Input
Voltage
HP KW Model
Qty
Req.
PartNumber
Resistor
specification
Qty
Req.
(set)
Specforone
Resistorand
dimensions
(L*W*H)mm
Qty
Req.
(pcs)
(Ω) (W)
220V
1/3Ф
100 75 JNTBU‐230 3 JNBR‐4R8KW6R8 4800W/6.8Ω 3
1200W/27.2Ω
(535*60*110)
12 108% 5.5Ω 3000W
125 90 JNTBU‐230 4 JNBR‐4R8KW6R8 4800W/6.8Ω 4
1200W/27.2Ω
(535*60*110)
16 113%
5.5
Ω
3000W
150 110 JNTBU‐230 4 JNBR‐4R8KW6R8 4800W/6.8Ω 4
1200W/27.2Ω
(535*60*110)
16 98%
5.5
Ω
3000W
Inverter Brakingunit Brakingresistor
Braking
torque
(Peak/
Continues)
10%ED
Minimum
Resistance
*1
Input
Voltage
HP KW Model
Qty
Req.
PartNumber
Resistor
specification
Qty
Req.
Specforone
Resistorand
dimensions
(L*W*H)mm
(Ω) (W)
440V
3Ф
1
0.75
‐ ‐ JNBR‐150W750 150W/750Ω 1
150W/750Ω
(251*28*60)
1 126% 120Ω 600W
2 1.5‐ ‐JNBR‐150W400 150W/400Ω 1
150W/400Ω
(251*28*60)
1 119% 120Ω 600W
3 2.2‐ ‐JNBR‐260W250 260W/250Ω 1
260W/250Ω
(274*40*78)
1 126% 100Ω 680W
5 3.7‐ ‐JNBR‐400W150 400W/150Ω 1
400W/150Ω
(395*40*78)
1 126% 60Ω 1200W
7.5 5.5‐ ‐JNBR‐600W130 600W/130Ω 1
600W/130Ω
(470*50*100)
1 102% 43Ω 1600W
10 7.5‐ ‐JNBR‐800W100 800W/100Ω 1
800W/100Ω
(535*60*110)
1 99% 43Ω 1600W
15 11‐ ‐JNBR‐1R6KW50 1600W/50Ω 1
1600W/50Ω
(615*60*110)
1 126% 43Ω 1600W
20 15‐ ‐JNBR‐1R5KW40 1500W/40Ω 1
1500W/40Ω
(615*60*110)
1 119% 22Ω 3000W
25 18.5 ‐ ‐ JNBR‐4R8KW32 4800W/32Ω 1
1200W/32Ω
(535*60*110)
4 119% 14Ω 4800W
30 22 ‐ ‐ JNBR‐4R8KW27R2 4800W/27.2Ω 1
1200W/27.2Ω
(535*60*110)
4 117% 14Ω 4800W
40 30 ‐ ‐ JNBR‐6KW20 6000W/20Ω 1
1500W/20Ω
(615*60*110)
4 119% 11Ω 6000W
50 37 JNTBU‐430 2 JNBR‐4R8KW32 4800W/32Ω 2
1200W/32Ω
(535*60*110)
8 119% 19.2Ω 3600W
60 45 JNTBU‐430 2 JNBR‐4R8KW27R2 4800W/27.2Ω 2
1200W/27.2Ω
(535*60*110)
8 117% 19.2Ω 3600W
75 55 JNTBU‐430 2 JNBR‐6KW20 6000W/20Ω 2
1500W/20Ω
(615*60*110)
8 126% 19.2Ω 3600W
