YOKOGAWA DL750 User Manual

4-5
IM 701210-05E
Common Operations
4
• Recalling Strings
Note that the string that is displayed in the entry box of the keyboard is overwritten
when a string is recalled using the procedure in step 1 below.
1. Every time the
soft key is pressed, strings that are temporary stored (strings
that have been entered previously) appear in order in the input box of the
keyboard. When the eight strings that are temporarily stored are displayed, the
most recent string is displayed again.
2. Make appropriate corrections to the recalled string and confirm it according to
steps 1 to 4 that were described in “Operating the Keyboard” on the previous
page. At this point, the confirmed string is temporarily stored.
• Keys Other Than the Character Keys
DEL: Deletes the character at the cursor.
INS: Switches the insert/overwrite mode. When in insert mode, the INSERT
indicator on the keyboard illuminates.
SPACE: Enters a space.
ENT: Confirms the displayed characters.
CAPS: Switches between uppercase and lowercase.
Number of Characters and Types That Can Be Used in the Settings
Setup Item Number of Characters That Reference
Characters Can Be Used Section
Date/Time Specified number 0 to 9 3.5
Waveform labels 1 to 8 All characters (including spaces) 8.10
Unit of linear scaling 0 to 4 All characters (including spaces) 5.11
File name 1 to 16 A to Z, %, _, (, ) 13.7 to 13.11,
7.7
Comments for files 0 to 160 All characters (including spaces) 13.7 to 13.10,
7.7
Comments for screen 0 to 20 All characters (including spaces) 13.11
images
Comments for printing 0 to 20 All characters (including spaces) 12.2
Message of annotation 0 to 80 All characters (including spaces) 9.4, 12.2
Comments for PDF files 0 to 20 All characters (including spaces) 13.13
Title, author, and sub 0 to 30 All characters (including spaces) 13.13, 9.9
title of PDF files
Keyword of PDF files 0 to 90 All characters (including spaces) 13.13, 9.9
E-mail address 0 to 40 ASCII characters (including spaces) 16.5
Comments for e-mail 0 to 30 All characters (including spaces) 16.5
User name, login name, 0 to 15 ASCII characters (including spaces) 16.3, 16.6,
and password 16.7
Note
• The multiple @ characters cannot be entered consecutively.
• File names are not case-sensitive. Uppercase and lowercase are distinguished in comments.
In addition, the following five file names cannot be used due to limitations of MS-DOS.
AUX, CON, PRN, NUL, CLOCK, COM1 to COM9, LPT1 to LPT9
4.2 Entering Values and Strings
