Setting the Number of Data Points to Be Used for Waveform Display: Decimation
Same as “Setting the Number of Data Points to Be Used for Waveform Display”
described in section 11.6.
For details, see section 11.6.
Selecting the Display Range of X-Y Waveforms: Start Point/End Point
The X-Y display shows the range selected on the T-Y waveform.
You can set the start (fine dashed line) and end (coarse dashed line) positions in the
range –5 to +5 divisions from the center of the waveform display frame. The start and
end positions are not displayed if only X-Y waveforms are displayed.
The resolution is as follows:
Resolution: T/div ×10 ÷ display record length
Notes When Displaying X-Y Waveforms
• The divided windows of the T-Y waveform display when using the T-Y & X-Y mode
are displayed according to Format in the DISPLAY menu.
• The zoom function applies only to T-Y waveforms. In addition, Main, Z1, or Z2 can be
selected for the T-Y waveform display.
• To expand the X-Y waveform, change Upper and Lower settings or V Zoom setting of
each channel. The displayed waveform can be enlarged/reduced in a similar fashion.
• To change the display position of the X-Y waveform, change the position of each
channel (for voltage input).
• X-Y waveform is not displayed when the horizontal axis of a waveform trace is in units
of time and the horizontal axis of another waveform trace is in units of frequency.
• Logic waveforms and event waveforms are not applicable to X-Y waveform display.
• When using the dual capture function, X-Y display and T-Y&X-Y display are not
possible.
8.6 Displaying X-Y Waveforms
