12-5
IM 701210-06E
Printing the Screen Image Data
12
Fine Print (When Fine Is Selected in Step 5)
Setting the Print Magnification
6. Press the Print Mag soft key, and use the jog shuttle to set the print
magnification. The number of pages that will be printed is displayed according
to the magnification.
Setting the Print Range
7. Press the Time Range1/Time Range2 soft key to set the jog shuttle control to
Time Range1.
8 Use the jog shuttle and SELECT to set the print start point.
9. Likewise, set Time Range2 (print end point).
Proceed to step 10.
Zoom Print (When Zoom Print Is Selected in Step 5)
Setting Zoom Box Z2
6. Press the Z2 Mag/Z2 Position soft key to set the jog shuttle control to Time Z2
Mag.
7 Turn the jog shuttle to set the zoom rate of the Z2 zoom box.
8. Likewise, set the zoom position of the Z2 zoom box with Z2 Position.
Proceed to step 10.
Note
• In zoom print, the range of zoom box Z2 (10 divisions) is printed.
• The Z2 Mag/Z2 Position setting is linked with the ZOOM menu (see section 8.5) setting.
Setting the Print Magnification
9. Press the Print Mag soft key, and use the jog shuttle to set the print
magnification. The number of pages that will be printed is displayed according
to the magnification.
Proceed to step 10.
12.2 Printing on the Built-in Printer
