Explanation
The screen image data can be stored to a specified storage medium.
You can select the storage medium from the floppy disk, Zip disk, PC card, external
SCSI device, internal hard disk (optional), and network drive (when the Ethernet
interface option is installed). For details on saving data to the network drive, see section
16.3.
Setting the Output Format
Data in the following formats can be saved to a specified storage medium. The
extension that is automatically attached and the file size (reference value) are indicated
below.
Output Data Format Extension File Size
1
PNG *.PNG Approx. 6 kbytes (Approx. 14 kbytes)
2
JPEG *.JPG Approx. 400k bytes (Approx. 400 kbytes)
2
BMP *.BMP Approx. 60 kbytes (Approx. 480 kbytes)
2
Post Script *.PS Approx. 123 kbytes
1. When color is OFF
2. The file size inside the parentheses is for the case when color is ON
Setting the Color (When Format Is BMP)
Select ON, ON(Revers), ON(Gray), or OFF.
ON: Output using 256 colors.
ON(Revers): Do not output the background of the screen in color.
ON(GRAY): Output the data using a tint of 16 gray levels.
OFF: Output in black and white.
Setting the Compression Format (When Format Is BMP and Color Is Not OFF)
When the output format is set to BMP, the data can be output by compressing using
RLE. However, data compression is not possible if the color is OFF.
Setting a Comment
A comment of up to 20 characters can be added to the lower section of the screen and
saved. Comments are optional. All characters (including spaces) can be used.
Setting the Save Destination: File List
The available storage medium is displayed in the File List window.
• Display Examples of Storage Media
[FD]: Floppy disk
[ZIP]: Zip disk
[PC Card]: PC card
[HD]: Hard disk
[SCSI5]: SCSI device with the ID number set to 5
1
[SCSI5-1]: Partition 1 of a SCSI device whose ID number is 5
1
[NetWork]: Network drive (when the Ethernet interface option is installed)
[USB]: USB storage device
1. When a SCSI device whose ID number is 5 is connected
Floppy Disk, Zip Disk, PC Card, Internal Hard Disk, External SCSI Device, and USB
Storage Device
Floppy disk, Zip disk, PC card, internal hard disk, and external SCSI device are
described in sections 13.1 to 13.4. For the formatting procedure, see section 13.5.
13.11 Saving Screen Image Data
