Ethernet Interface (Optional)
16
• Setting the Trend Display Conditions
Selecting the Waveform Parameter to Be Displayed (Graph 1 and Graph 2)
You can display two trend graphs. For each graph, you can specify the trend target
waveform and the waveform parameter. When the waveform parameter is “Marker,”
you can set the Marker Position.
Selecting the Target Waveform (Trace)
From the Trace box, select the target waveform for the trend display from the
following:
Chan1 to Chan16 (channels 1 to 16), DSP1 to DSP6 (optional), Math1 to Math8
(computed waveforms)
Selecting the Waveform Parameter
From the Parameter box, select the target waveform parameter of the trend display
(same expression as the communication command) from the following: For the
meanings of the waveform parameters and the marker cursor, see the explanation
in section 11.6 or 11.5.
Parameter DL750/DL750P Menu Parameter DL750/DL750P Menu
None Not selected MINIMUM Min
AMPLITUDE Amp NOVERSHOOT -OShot
AVERAGE Avg NWIDTH -Width
AVGFREQ AvgFreq PERIOD Period
AVGPERIOD AvgPriod PNUMBER Pulse
BWIDTH1 Burst1 POVERSHOOT +OShot
BWIDTH2 Burst2 PTOPEAK P-P
DELAY Delay – –
(For a detail setting, use Delay Setup on the DL750/DL750P)
DUTYCYCLE Duty PWIDTH +Width
FALL Fall RISE Rise
FREQUENCY Freq RMS Rms
HIGH High SDEVIATION Sdev
LOW Low TY1INTEG Int1TY
MAXIMUM Max TY2INTEG Int2TY
Marker(M1<2>) M1<2> XY1INTEG Int1XY
(marker cursor for cursor measurements)
MIDDLE Mid XY2INTEG Int2XY
Setting the Marker Position
You can set the marker position if “Marker(M1)” or “Marker(M2)” is selected as the
waveform parameter.
Setting the Conditions for Retrieving the Measured Values of Waveform
Parameters (Common)
Number of Displayed Measured Values (Data Number)
Select the number of measured values (measured values retrieved from the
DL750/DL750P into the PC) to be displayed in the cells of Excel from the following:
If the number of measured values exceeds the selected number, the values are
cleared from the oldest values to display the newest measured values.
10, 20, 50, 100, 200, and 500
Retrieve Interval
Select the retrieve interval from the following. However, of the selected waveform
parameters, select the interval to match the longest parameter cycle measured on
the DL750/DL750P.
2 s, 5 s, 10 s, 30 s, and 60 s
16.7 Using the Web Server Function
