18-12

IM 701210-06E

Code Message and Corrective Action Section

1605 Repeat trigger cannot be specified. Chapter 9

Repeat trigger is valid only during chart recorder mode when the print style is waveform and shot

recording is not OFF.

1606 Cannot be changed during X-Y recording. 9.7

1607 Cannot use wave window trigger when the recorder mode is set to chart or X-Y. Chapter 9

1608 Cannot be specified when the print style is Numeric. 9.6

1609 Cannot Set or Execute on the DL750. Chapter 9

Other Errors (9999)

Code Message and Corrective Action Section

9999 This error No. is not defined. –

Note

If servicing is required, initialize the instrument once for confirmation.

18.2 Messages and Corrective Actions
