19-15
IM 701210-06E
Specifications
19
DC Option (DL750 Only)
Item Specifications
Supply format Auto DC/AC switching (AC preferred), isolation between DC power input terminal and the DL750
Rated supply voltage 12 VDC
Permitted supply voltage 10 to 18 VDC
Power consumption Approx. 40 VA (typical*1): When printer is OFF and two channels are used
Approx. 60 VA (typical*1): When printer is OFF and eight channels are used
Approx. 80 VA (typical*1): When printer is OFF and 16 channels are used
Maximum power Approx. 120 VA Max.
consumption
Standby power 30 mW (typical*1, DC power consumption when power is supplied both to AC and DC power)
(during DC standby)
Voltage input protection Overcurrent detection: Breaker (15 A)
circuit Reverse connection protection: Breaker shutdown
Undervoltage detection: Cut off at a voltage less than approx. 9.5 V
Overvoltage detection: Cut off at a voltage greater than approx. 18 V
Withstand voltage 30 VAC for one minute between the DC power input terminal and earth terminal
Insulation resistance 10 MΩ or more at 500 VDC between the DC power terminal and earth
External dimensions 355 mm (W) × 250 mm (H) × 200 mm (D) (DL750 with the /DC option installed, excluding the handle
and other projections)
Weight Approx. 7.4 kg (only the DL750 with all options (/M3/C8/C10/P4/DC options)
Approx. 9.8 kg (DL750 (with /DC option) + eight High-speed 10 MS/s, 12-Bit Isolation Modules)
Weight increase by the DC power option Approx. 800 g
Indicator function Indicates the status of the power supply to the DL750 using two LEDs
Accessories The following items are added to the standard accessories.
Soldering-type DC power connector (B8023WZ)
* Same specifications as the standard model for standard operating conditions, storage temperature, storage humidity, storage
altitude, operating temperature range, operating humidity range, operating altitude, and battery backup.
*1 Typical value represents a typical or average value. It is not a warranted value.
19.11 General Specifications
