19-16
IM 701210-06E
19.11 General Specifications
Item Specifications
Safety standard Complying standard EN61010-1
• Installation category (overvoltage category) II
1
• Measurement category II
2
• Pollution degree 2
3
Already certified (701210/701230/701250/701251/701255/701260/
701261/701262/701265/701270/701271/701275/701280/700986/700987/
701955/701956/701957/701958)
Emission Complying standard EN61326-1 Class A
EN61326-2-1
EN55011 Class A, Group 1
C-tick EN55011 Class A, Group 1
Already certified (701210/701230/701250/701251/701255/701260/
701261/701262/701265/701270/701271/701275/701280/700986/700987/
701955/701956/701957/701958)
EN61000-3-2
EN61000-3-3
• This product is a Class A (for industrial environment) product. Operation
of this product in a residential area may cause radio interference in which
case the user is required to correct the interference.
Cable condition • Shared external trigger/external clock input terminal
Use the BNC-RCA adapter (YOKOGAWA: 366928) and a BNC cable
4
and attach a ferrite core (TDK: ZCAT2035-0930A, YOKOGAWA:
A1190MN) on one end (DL750/DL750P side).
• Trigger output terminal
Same as the external trigger input terminal above.
• Video signal output (VIDEO OUT (SVGA)) terminal
Use a 15-pin D-Sub VGA shielded cable
4
.
• GP-IB interface connector
Use shielded GP-IB cables
4
.
• Serial (RS-232) interface connector
Use an shielded RS-232 cable
4
and attach a ferrite core (TDK:
ZCAT2035-0930A, YOKOGAWA: A1190MN) on one end (DL750/
DL750P side).
• SCSI interface connector
Use shielded SCSI cable
4
and attach a ferrite core (TDK: ZCAT2035-
0930A, YOKOGAWA: A1190MN) on one end (DL750/DL750P side).
• USB peripheral connector
Use shielded USB cables
4
.
• USB interface connector
When connecting a USB keyboard or mouse using a shielded cable or
when connecting to a USB printer, use shielded USB cables
4
.
• GO/NO-GO I/O terminal
Use a dedicated GO/NO-GO cable (YOKOGAWA: 366937) sold separately.
• Ethernet connector
Use category 5 Ethernet cables
5
or better cables.
• Probes connected to modules and wiring
Use twisted pair cables when connecting items other than probes to the
module. Attach a ferrite core (TDK: ZCAT2035-0930A, YOKOGAWA:
A1190MN) to the probes and cables that are connected to the modules.
Wrap the cable around the ferrite core once.
• Logic probe input
Attach a ferrite core (TDK: ZCAT2035-0930A, YOKOGAWA: A1190MN)
on one end (DL750/DL750P side) of the cable to be connected to the
logic probe input terminal.
• Current probe (700937, 701930, 701931, 701933)
When connecting a current probe to the input terminal and probe power
terminal of the module, attach a ferrite core (TDK: ZCAT2035-0930A,
YOKOGAWA: A1190MN) on one end (DL750/DL750P side) of the two
cables together.
• Voice memo terminal
Earphone microphone with a switch
4
(4-pin jack microphone connectable
to NTT DOCOMO portable phones)
(Cannot be used on the current software version that you are using.)
• Bridge Head for the Strain Module
When using the 701270, use the 701955 or the 701956; when using the
701271, use the 701957 or the 701958.
• DC power cord
Attach a ferrite core (TDK: ZCAT3035-1330A, YOKOGAWA: A1179MN)
to the DC power cord.
To Next Page
