19-43

IM 701210-06E

Specifications

DL750P

Unit: mm

13.5 355

2508

225 9

ACQ MEMORY

BACKUP BATTERIES

Rear View

If not specified, the tolerance is ±3%. However, in cases of less than 10 mm, the

tolerance is ±0.3 mm.

19.14 External Dimensions
