Altera Corporation 9–9
July 2005 Stratix Device Handbook, Volume 2
Implementing SFI-4 in Stratix & Stratix GX Devices
Tables 9–2 and 9–3 list the number of SFI-4 cores that can be implemented
in Stratix and Stratix GX devices. See the High-Speed Differential I/O
Interfaces in Stratix Devices chapter in the Stratix Device Handbook or the
Stratix GX Device Handbook for the package type and the maximum
number of channels supported by each package.
Table 9–2. Stratix SFI-4 Core Support
Stratix Device
Number of LVDS
Channels
(Receiver/Transmitter)
(1)
Number of PLLs
Number of SFI-4
Interfaces
(Maximum)
EP1S10 44/44 4 2
EP1S20 66/66 4 2
EP1S25 78/78 4 2
EP1S30 82/82 8 4
EP1S40 90/90 8 4
EP1S60 116/116 8 4
EP1S80 152/156 8 4
Note to Ta b le 9 – 2 :
(1) The LVDS channels can go up to 840 Mbps (or 1 Gbps using DPA in Stratix GX
devices). This number includes both high speed and low speed channels. The
high speed LVDS channels can go up to 840 Mbps. The low speed LVDS channels
can go up to 462 Mbps. The High-Speed Differential I/O Support chapters in the
Stratix Device Handbook, Volume 1 and the Stratix GX Device Handbook, Volume 1
and the device pin-outs on the web (www.altera.com) specify which channels are
high and low speed.
Table 9–3. Stratix GX SFI-4 Core Support
Stratix GX
Device
Number of LVDS
Channels
(Receiver/Transmitter)
(1)
Number of PLLs
Number of SFI-4
Interfaces
(Maximum)
EP1SGX10 22/22 2 1
EP1SGX25 39/39 2 2
EP1SGX40 45/45 4 2
Note to Ta b le 9 – 3 :
(1) The LVDS channels can go up to 840 Mbps, or 1 Gbps using DPA. This number
includes both high speed and low speed channels. The high speed LVDS channels
can go up to 840 Mbps. The low speed LVDS channels can go up to 462 Mbps. The
High-Speed Differential I/O Support chapter in the Stratix Device Handbook, Volume
1 and the Stratix GX Device Handbook, Volume 1 and the device pin-outs on the web
(www.altera.com) specify which channels are high and low speed.
