17.
Follow the software installation for TLC according to the information on the monitor:
➠ Use hardware keys only:
, or
[AQ] (
Alarm Acknowledgement
)= NO =
[EQ] (Enter) = YES =
➠ Do not connect and use a PC keyboard for the installation of the software.
*** You are about to install the Dialog/TLC V9.xx software. ***
If you want to CONTINUE the Installation,
LEAVE the installation USB stick in the socket,
press Y or y and <CR> if keyboard is used
otherwise
press the EQ hardware key!
If you want to SKIP the TLC installation
press N or n and <CR> on keyboard or any other hardware key!
[EQ]
Press to confirm and proceed with the installation of the TLC software.
[AQ]
Press if you want to terminate the installation of the software.
LX800 Motherboard
*** Dialog V9.xx /TLC V9.xx installation ***
Installation/setup of the Dialog/TLC runtime system.
Does the machine have:
LX800 (NIBP: COM3=IRQ9 ECG: COM4=IRQ5) motherboard?
If YES, press Y or y and <CR> if keyboard is used
otherwise
press the EQ hardware key!
If NO, press N or n and <CR> on keyboard or any other hardware key!
[EQ]
Press to select the LX800 motherboard.
Selected motherboard: LX800 (NIBP: COM3=IRQ9 ECG: COM4=IRQ5)
Are you sure ?
If YES, press Y or y and <CR> if keyboard is used
otherwise
press the EQ hardware key!
If NO, press N or n and <CR> on keyboard or any other hardware key!
[EQ]
Press to confirm the selected LX800 motherboard.
Compact Flash Card CFC
Does the machine have:
CF-Card_Swissbit-SFCF1024H3BKZSA_I-MO-513_SID_1.00GB (h=16 s=63) harddisk?
If YES, press Y or y and <CR> if keyboard is used
otherwise
press the EQ hardware key!
If NO, press N or n and <CR> on keyboard or any other hardware key!
[EQ]
Press to select the CFC.
Selected harddisk: CF-Card_Swissbit-SFCF1024H3BKZSA_I-MO-513_SID_1.00GB (h=16
s=63)
Are you sure ?
If YES, press Y or y and <CR> if keyboard is used
otherwise
press the EQ hardware key!
If NO, press N or n and <CR> on keyboard or any other hardware key!
[EQ]
Press to confirm the selected CFC.
