3. Repair Instructions 1/2010 3 - 70
BA-TE-DE08C M.KAY
Dialog+ SW9xx_sm_Chapter 3_1-2010.doc/pdf <100329> yymmdd
B. Braun Avitum AG
Dialog
+
SW 9.xx
Field Service Utilities V2.00 - SetMST
CRC = XXXX - OK
Write System Configuration (USB Stick - > Dialog+ Hard Disk)
No source is found...
AQ
: back to previous menu
The utility searches for sources. An input screen can
open with the following information (see left figure),
i.e. no sources were found on the USB stick because the
system configuration data subdirectories are empty.
System configuration data must be stored to the USB
stick before you can write system configuration data to
the Dialog+ hard disk drive (CFC).
3.
Press
AQ
to go back to the previous menu.
4.
Use the
Read System Configuration
utility to read
the system configuration data from the Dialog+
hard disk drive (CFC) to the USB stick.
Field Service Utilities V2.00 - SetMST
CRC = XXXX - OK
Write System Configuration (USB Stick - > Dialog+ Hard Disk)
Writing System Configuration to Dialog+ from: TLCver=90832/VX_XX
Are you sure?
AQ
: no
EQ
: yes
An input screen opens to
Write System Configuration
to
the hard disk drive (CFC) with the following hardware
keys:
AQ
:
No, system configuration file is not written
to Dialog+, exit from the utility
EQ
Yes, system configuration file is written to
Dialog+ hard disk drive (CFC)
