3. Repair Instructions 1/2010 3 - 97
BA-TE-DE08C M.KAY
Dialog+ SW9xx_sm_Chapter 3_1-2010.doc/pdf <100329> yymmdd
B. Braun Avitum AG
Dialog
+
SW 9.xx
Unit HD HDF Online US Default Modified
HDF/HF Online Parameters
HDF Substitution Flow ml/min - 60 -
HF Substitution Flow ml/min - 100 -
HDF Dialysate Flow for Postdilution ml/min - 600 -
HDF Dialysate Flow for Predilution ml/min - 700 -
HDF/HF Infusion Bolus Volume ml - 100 -
Post-/Predilution Selection - - inactive -
Disinfection Parameters
Disinfection after each Therapy - NO YES NO
Automatic Preparation Start after Disinfection - NO NO NO
Thermal Disinfection - YES NO YES
Chemical Disinfection - YES YES YES
Chemical Disinfection, Short - YES NO NO
Central Thermal Disinfection - NO NO NO
Central Manual Chemical Disinfection - NO NO NO
Central Automatic Chemical Disinfection - NO NO NO
Rinsing - NO NO YES
Automatic Switch-On with Rinsing - No Weekly Schedule - inactive inactive inactive
Switch-On Time h:min 06:30 06:30 06:30
Automatic Switch-On by Weekly Schedule - active active active
Weekly Schedule (see Table)
Start on Sunday - inactive inactive active
Start on Monday - active active inactive
Auto Switch-On without daily confirmation
-NONONO
Maximum Out of Action Time - inactive inactive active
Days Days 0 0 2
Hours/Minutes h:min 08:00 08:00 00:00
Disinfection Configuration Data Table - Citric Acid 50% Citric Acid 50% Citric Thermal
Central Thermal: Inlet Flow ml/min 250 250 250
Central Thermal: Time h:min 00:30 00:30 00:30
Central Manual Chemical: Inlet Flow ml/min 250 250 250
Central Manual Chemical: Inlet Time h:min 00:05 00:05 00:05
Central Manual Chemical: Rinsing Flow ml/min 800 800 800
Central Manual Chemical: Rinsing Time h:min 00:30 00:30 00:30
Central Automatic Chemical: Inlet Volume ml 260 260 260
Central Automatic Chemical: Switch off for Retention
without Automatic Switch-On
-NONONO
Central Automatic Chemical: Retention Time h:min 00:20 00:20 00:20
Central Automatic Chemical: Rinsing Flow ml/min 800 800 800
Central Automatic Chemical: Rinsing Time h:min 00:30 00:30 00:30
Rinsing: Inlet Flow ml/min 800 800 800
Rinsing: Time h:min 00:02 00:02 00:02
Filter Parameters
Name - Diacap-Ultra Diacap-Ultra Diacap-Ultra
Therapy Number - 150 150 150
Filter Operation Time h 900 900 900
Dialyser Parameters (Kt/V)
Urea Distribution Volume Formula - Watson Watson Watson
Height Measurement Unit of Watson Formula - cm cm cm
Default Target Kt/V - 1.20 1.20 1.20
Default Setting for Treatment Mode Warning of Kt/V
Target Projected Deviation
- Warning active Warning active Warning inactive
Kt/V Table - Manual Input: Setting Clean/Total Blood [%] - YES YES YES
Warning for Saving Kt/V Volume enabled - NO NO NO
Kt/V-UV
Default Target Kt/V - 1.20 1.20 1.20
Kt/V Correction Mode - Single Pool Single Pool Single Pool
Default Setting for Treatment Mode:
Warning of Kt/V Target-Projected Deviation
-
Warning active Warning active Warning inactive
Warning for Saving Kt/V Table - NO NO NO
Timings
Parameter Setting Window Disappearing Time s 500 500 600
Screen Saver Appearance - NO NO NO
Appearing Time s 600 600 600
