3. Repair Instructions 1/2010 3 - 96
BA-TE-DE08C M.KAY
Dialog+ SW9xx_sm_Chapter 3_1-2010.doc/pdf <100329> yymmdd
B. Braun Avitum AG
Dialog
+
SW 9.xx
Unit HD HDF Online US Default Modified
Single Needle Parameters
Single Needle Valve
Limit Min. PA mmHg -200 -200 -200
Max. Control Min. PV mmHg 150 150 150
Control Min. PV mmHg 100 100 100
Control Max. PV mmHg 350 350 390
Single-Needle Cross-Over
Control PA mmHg -180 -180 -180
Control PV mmHg 360 360 360
Heparin Parameters
Treatment without Heparin - NO NO NO
Heparin Measurement Unit - ml/h ml/h ml/h
Conversion Factor Heparin (IE/ml) - 1000 1000 1000
Heparin Rate ml/h 3.0 3.0 3.0
Heparin Bolus Volume ml 0.0 0.0 0.0
Therapy Beginning Bolus - NO NO NO
Selected Syringe Type - Omnifix 30 ml Omnifix 30 ml B-D 10 ml
Syringe Table
Heparin Pump Compact
Syringe Sizes: 10 ml to 30 ml
Syringe Type Inside Diameter [mm]
Braun OPS 20 ml 19.00
Terumo 20/25 ml 20.10
Terumo 30/35 ml 22.57
B-D (for US) 10 ml 14.43
B-D 20 ml 18.90
B-D 30 ml 21.53
Monoject 20 ml 19.83
Dispomed 30 ml 22.17
Fresenius HS 30 ml 22.20
Omnifix 10 ml 16.05
Omnifix 20 ml 19.80
Omnifix 30 ml 22.00
Unit HD HDF Online US Default Modified
Rinsing Parameters
Priming without Recirculation - NO NO NO
Filling BP Rate ml/min 100 100 100
Filling BP Volume ml 700 700 500
Automatic Rinse Program after Self Tests - YES YES YES
User Message for BS Filled? - YES YES YES
Rinsing Blood Flow ml/min 200 200 200
Rinsing Dialysate Flow ml/min 500 500 600
Rinsing Time by UFP h:min 00:59 00:59 00:10
Rinsing Rate by UFP ml/h 203 203 600
Rinsing Volume by UFP ml 200 200 100
Rinsing Time by BPA or BPV h:min - 00:30 -
Rinsing Rate by BPA or BPV ml/h - 6000 -
Rinsing Volume by BPA or BPV ml - 3000 -
Blood Flow for Connecting Patient ml/min 100 100 100
UF Parameters
Minimal UF Rate ml/h 50 50 50
UF Rate Compensation? - YES YES YES
Max. Value of Upper Limit UF Rate ml/h 3000 3000 3000
Default Value of Upper Limit UF Rate ml/h 2000 2000 2000
UF Volume ml 2000 2000 2000
Therapy Time h:min 04:00 04:00 03:30
Gross UF Rate vs. Blood Flow - inactive inactive inactive
%40 40 40
Gross UF Rate vs. Blood Flow - active active active
%30 30 30
UF Profile Editor
