B. Braun Dialog+ - Page 301

4. TSM Service Program 1/2010 4 - 132
BA-TE-DE08W M.KAY Dialog+ SW9xx_SM_Chapter 4-3-1_1_2010.doc/pdf <110301> yymmdd B. Braun Avitum AG
Dialog
+
SW 9.xx
BL
VDE
TSDE
VD
PDA
Y1
FBK2
FBK1
VEBK2
VDEBK2
VDABK1
VABK2
VDEBK1
VEBK1
FPE
Fig.: Original Tubing Rinsing Bridge with TSDE Fig.: Original Tubing UF Sub-Rack with FBK1
BL
V
DE
VD
PDA
Y1
TSDE
FBK2
FBK1
FPE
blue
red
Measurement
Sensor
Measurement
Instrument
C
mS/cm
o
ml/min
D
blue
red
Fig.: Tubing Rinsing Bridge with Removed TSDE Fig.: UF Sub-Rack with TSDE in Line with TSBIC/TSD/TSD-S (on DF Sub-Rack)
for Calibration
