Calibration Point 30
o
C 8. Increase slowly heater power (in %) until a stable temperature value of 30
o
C ±2
o
C is displayed at the temperature measurement instrument.
Note: Pay attention to the maximum fluctuation of ±0.1 °C over 10 s at
the temperature measurement instrument.
9. Press
key.
Wait until digits are stable.
10. Enter the stable value from the temperature measurement instrument as
reference value.
11. Confirm with
key.
Calibration Point 38
o
C
12. Increase slowly heater power until a stable temperature value of 38 °C ±2
°C is displayed at the temperature measurement instrument.
Note: Pay attention to the maximum fluctuation of ±0.1 °C over 10 s at
the temperature measurement instrument.
Write down the value of the heater power, because this value is
required for the calibration of the conductivity.
13. Press
key.
Wait until digits are stable.
14. Enter the stable value from the temperature measurement instrument as
reference value.
15. Confirm with
key.
Calibration Point 50
o
C
16. Increase slowly heater power until a stable temperature value of 50
o
C ±2
o
C is displayed at the temperature measurement instrument.
Note: Pay attention to the maximum fluctuation of ±0.1 °C over 10 s at
the temperature measurement instrument.
The flow can be reduced slightly if the heater power (100%) is insufficient for
the last calibration point.
17. Press
key.
Wait until digits are stable.
18. Enter the stable value from the temperature measurement instrument as
reference value.
19. Confirm with
key.
20. Confirm and save the completed calibration procedure with
key.
Note: The calibration data is saved only after the bit sequence 0-1-0 (for
detailed information see 4.8.3.1 General Calibration Information).
21. Reassemble the heater inlet temperature sensor TSDE to the original
position (see previous page).
Note: Pay attention to correct flow direction of temperature sensor TSDE.
