4. TSM Service Program 1/2010 4 - 163
BA-TE-DE08W M.KAY Dialog+ SW9xx_SM_Chapter 4-3-1_1_2010.doc/pdf <110301> yymmdd B. Braun Avitum AG
Dialog
+
SW 9.xx
• Manometer 0 to 4 bar (art. no. 7701357 or equivalent)
• Flow meter (art. no. 770085A or equivalent)
• Allen key 3 mm
Please ensure that the manometer and connection tubing are at the same
level as the balance chamber/rinsing bridge and dialyser during calibration.
1. Remove lower front cover.
2. Connect manometer and flow meter between flow pump FPE and FBK1.
3. Select Test 1.20 Water Part (Overview) in TSM.
4. Increase slowly the speed of FPA, until a flow of 500 ml/min is reached.
5. Set temperature TSD to 37
o
C and wait until temperature is reached.
6. Loosen lock nut on RVDA adjustment screw.
7. Set a pressure of 300 mmHg/400 mbar (HDF online 375 mmHg/500 mbar)
with the adjustment screw of RVDA.
• 300 mmHg ±37 mmHg
• 400 mbar ±50 mbar
HDF Online
• 375 mmHg ±37 mmHg
• 500 mbar ±50 mbar
8. Tighten lock nut again.
9. Remove manometer and flow meter.
