Brooks Marathon Express - Page 103

Brooks Automation 5. Operational Interfaces
Part Number: 605914 Rev. B Heater Power Supply Remote
Pin Signal
7 OnSenseRelay
8 24VDCReturn
9 
10 
11 
12 
13 
14 ReadyRelay
15 

Figure 5-1: Heater Remote Control Connector Wiring
RefertotheSystemBlockDiagramandVacuumandVentDiagramssuppliedwiththismanualand
to"RemoteOperation"onpage128foroperation.
