1. Introduction Marathon Express
Specifications Part Number: 605914 Rev. B
Figure 1-2: Marathon Express Space Requirements

Model Width Depth Height Width
MX600
1416.1mm(55.75
in)
1462.3mm(57.57
in)
1442.5mm(56.79
in)
900.0kg(1984lb)
MX700
1416.1mm(55.75
in)
1442.7mm(56.80
in)
1442.5mm(56.79
in)
1014.0kg(2236
lb)
MX800
1431.8mm(56.37
in)
1479.3mm(58.24
in)
1444.0mm(56.85
in)
1451.5kg(3200
lb)
Table 1-7: Space Specifications

Communications Specifications
Refertothecontrolsmanualforcommunicationsspecifications.
24
