Brooks Marathon Express - Unpacking and Inspection

Brooks Automation 3. Installation
Part Number: 605914 Rev. B Unpacking and Inspection
Environmental
ThesitefortheMarathonExpressmustmeettheminimumenvironmentalrequirementsspecifiedin
"EnvironmentalSpecifications"onpage18toensureproperoperationoftheMXsystem.
Facilities
Theuserisresponsibleforprovidingthefacilitiesspecifiedin"FacilitiesSpecifications"onpage21
fortheMarathonExpresstoensureproperoperationoftheMXsystem.Referto"Facilities
Connections"onpage69fortheconnectionofallfacilitiestotheMXsystem.Referto"Operational
Interfaces"forthewiringofallelectricalconnections.
TheuserisresponsibleforthemaindisconnectdevicebetweentheMarathonExpressandthe
facility’spowersource,ensuringitcomplieswiththecorrectelectriccodes.Themainuserinstalled
disconnectdevicemustmeet,orexceed,theminimumAICratingspecifiedbySEMIS2(10,000AIC
minimum).ServicetotheMXsystemshouldhavetheappropriatefuseorcircuitbreakerrating.
Unpacking and Inspection
TheBrooksAutomationMarathonExpressisshippedinseparatepackageswhichareindividually
sealedtomaintaincleanroomconformance.Unpackeachcratecarefullyfollowingthesteps
providedin"UnpackingInstructions";inspectandverifythecontentsagainstthechecklistprovided
onthefrontpageoftheAT.ReportanydamageimmediatelytotheshipperandtoBrooks
Automation.
Onesetofshippingdocumentswillbeattachedtotheoutsideofthemainshippingcrateforeasy
access.Anadditionalsetofthesamedocumentswillbeattachedtotheequipmentinsidethe
shippingcrate.
NOTE: Thenumberandcontentsoftheshippingcrateswilldependontheitems
purchased.RefertotheATfortheexactcontents.Table3-1,below,isprovidedfor
referenceonly.

Package Typical Contents
Marathon
Express
l
Chambermountedonframewithwheelswithinstalledoptionsthatmayinclude:therobot,
VCEloadlocks,customendeffector,aligner,etc.
Table 3-1: Packing Checklist Reference
Copyright © 2023, Brooks Automation, Inc.
55
