Electrical Hazards
AtmaximumloadtheMarathonExpressiscapableofdrawing8Ampsat200-240VAC.The
minimumovercurrentratingsfortheMarathonExpresssystemdisconnectsrequiresauserinstalled
200-208VAC,10A,slowblowcircuitbreaker(10,000AICminimum).Theminimumovercurrent
ratingsfortheHeatingSystemdisconnectsrequiresauserinstalled3-phase200-208VAC,20A,
slowblowcircuitbreakerthatmeets,orexceeds,therequirementsofSEMIS2(10,000AIC
minimum).
Theproperprecautionsforoperatingandservicingelectricalequipmentmustbeobserved.These
precautionsincludefollowingfacilitylockout/tagoutprocedures,andanyotherspecifiedaction
withinthefacilitywheretheMarathonExpressisbeingused.Ifnosuchproceduresexist,followthe
guidelinesprovidedin"LaserHazards"onpage46.

Electrical Shock
MaximumpowerconsumptionfortheMarathonExpressduringnormaloperationis200-
240VACat8AmpsandfortheMarathonExpressHeatingSystemduringbake-out
operationsis200-240VACat17Amps.Improperhandlingofthepowersourceor
connectingdevicesmayinduceelectricalshockorburnresultinginseriousinjuryor
deathorcauseanequipmentfire.

AllpowertoMarathonExpressmustbedisconnectedperthefacility’slockout/tagout
procedurebeforeservicingtopreventtheriskofelectricalshock.

Approximately1000watts(240volts@4.2A)ispresentateachheatingelement

Approximately108VACispresentattheconnectiontoanyHotCathodeIonGauges
duringoperation.

AlwaysprovidetheMarathonExpresssystemwiththeproperelectricalcodecompliant
connections.

Workingwithenergizedequipmentmaycauseelectricalshockandmayresultindeathor
seriousinjury.
l
Allenergymustberemovedfromtheequipmentperthefacility’sLockout/Tagout
procedurebeforeservicing.
l
FollowtheLockout/Tagoutproceduresspecifiedbythelocalfacility.
l
Iflocalproceduresarenotavailable,followtheprocedureforLockout/Tagoutin
OSHA Standard 29CFR 1910.147.
l
Refertheunitsspecificationsfortheactualsystempowerrequirementsanduse
appropriateprecautions.

