5. Operational Interfaces Marathon Express
Heater Power Supply Remote Part Number: 605914 Rev. B
5. Operational Interfaces
TheseinterfacesprovidepowertotheMXsystemandcommunicationsfromtheMarathonExpress
systemtothehostcontrollertoallowittomonitorandcontrolallcomponents.
Refertotheappropriatemanuals,SystemBlockDiagram,andVacuumandVentDiagrams
suppliedwiththismanual.
Heater Power Supply Remote
TheoptionalHeaterControlPowerSupplyiscapableoftwomodesofoperation:Standard,whereit
willoperateonlyfromitsFrontPanel,andRemote,wherebasiccontrolsandindicatorsforthe
powersupplyareavailablefromaremotelocation.RefertoTable5-1fortheconnectorpinoutand
Figure5-1forconnectiondiagrams.Notethatpinsnotidentifiedwithasignalnamearetobeleft
unconnected.
TheRemoteControlcircuitistheresponsibilityoftheuser.

Pin Signal
1 +24VDC
2 UserInterlock
3 RemoteOn1
4 RemoteOn2
5 RemoteOff1
6 RemoteOff2
Table 5-1: Heater Remote Control Connector
Pinout
