Brooks Automation 6. Operation
Part Number: 605914 Rev. B Safety Interlocks
Figure 6-7: Ethernet Switch Module - Controls and Indicators
Name Type Function
Power GreenLamp
Power
Normalcondition:ON
10/100M(8X) GreenLamp
ConnectionSpeed
ON:100Mbps
OFF:10Mbps
Link/Act(9X) GreenLamp
LinkStatus/Activity
ON:PortconnectedOff:
Portnotconnected
Blink:Portactive
FDX/Col(8X) GreenLamp
DuplexMode/Collisions
ON:Fullduplex
Off:Halfduplex
Blink:Datatransferpacketcollisions
VLAN SlideSwitch Turnson/offVLANoption-refertoSwitchUserManualfordetails.
Table 6-5: Ethernet Switch Module - Controls and Indicators
Safety Interlocks
TheMarathonExpressisprovidedwithsafetyinterlockstoensurethesafetyoftheoperatorsand
servicepersonnel.Thelocationandfunctionofeachoftheseinterlocksisidentifiedbelow.
