3. Installation Marathon Express
Installation Procedure Part Number: 605914 Rev. B
Figure 3-8: Marathon Express Interface Locations (continued)
Electrical
ElectricalpowerisconnectedtotheMarathonExpressforoperationoftherobot,elevators,
sensors,andothersubsystems.A200-240VACelectricalconnectionisprovidedontheMarathon
ExpressforACpowerfromthefacility.Referto"FacilitiesSpecifications"onpage21forelectrical
requirements.Ensurethattheelectricalconnectionisfortheappropriatevoltage.
Electrical Shock
TurnontheelectricalsupplybeforeconnectingthefacilitiestotheMarathonExpresscan
causepersonalinjuryordeath.
DonotturnontheelectricalsupplyfromthefacilityuntilallconnectionstotheMarathon
Expressandallinstallationprocedureshavebeencompleted.

