8. System Alignment Marathon Express
Overview Part Number: 605914 Rev. B
NOTE: Evenasmallmis-alignmentcaninterferewithpropersystemoperationand
causeunnecessarydowntime.Followallstepstoensureprecisealignment.
Procedure Category
Type2Procedure:Equipmentisenergizedandallenergizedcircuitsarecoveredorinsulated.All
workisperformedremotelyusingtheCDMorservicecomputer.
Required Tools and Test Equipment
Performingthealignmentprocedurerequiresthefollowingtoolsandmaterials:
l
TheparametersheetfortheMarathonExpresssystem’sstationsfromtheSystemAcceptanceTest
(ATP)shippedwiththesystem
l
AcomputerrunningaterminalemulatororadumbterminalwithaRS-232mSerialcommunications
connection
l
ASerialCommunicationCable
l
AsetofHexwrenchesininchsizes
l
AsetofHexwrenchesinmetricsizes
l
15/16inchopenendorsocketwrench
l
A150mm(6in)steelrulergraduatedinhundredths
l
TheControl/DisplayModule(CDM)fortherobot
l
2processcassettesofthetypeusedinnormalprocessing
l
MicroToolDummyWafersortestmaterialofthesizeforwhichthesystemisbeingsetup(minimumof10
wafers)
l
MicroToolElectroniclevelorequivalent(bubblelevel)
l
A1m(3ft)bubblelevelorequivalent
l
Systemteachfixtures
l
TheusermanualsforallcomponentswithintheMarathonExpress
l
TheusermanualsforanydevicesinterfacingwiththeMarathonExpress
Alignment Strategy
TheMarathonExpressisanAtmospherictoVacuumClusterToolIntegrationPlatformforProcess
Modules.ToproperlyaligntheMXsystemitmustbeattachedtotheProcessModulesitwillbeused
with.
TherobotwithintheMXsystemdoesnothavelevelingadjustments.Therobotismounteddirectly
tothechamberoftheMarathonExpressVacuumBackEnd.AdjustmentoftheMXsystem’s
modulesispartofthealignmentoftheMarathonExpressduringinstallation.Allcomponentsofthe
MXsystemmustbeleveledrelativetotherobot.
Theproceduresprovidedhereareforabasicsystemalignment.Refertotheappropriateuser
manualsfordetailedalignmentinformation.
NOTE: Athoroughalignmentprotectsagainstequipmentdamageandmisalignedor
slidingmaterial,whichcouldleadtopersonalinjury.
