6. Operation Marathon Express
Controls and Indicators Part Number: 605914 Rev. B
Figure 6-6: Ethernet to Serial Gateway Module - Controls and Indicators
Name Type Function
LNKACT RedLamp IndicatesworkingEtherNetconnection
100MB RedLamp
Connectionspeed
ON:100Mbps
OFF:10Mbps
DUP RedLamp Indicatesfullduplexmode
RX GreenLamp
Serialcommunicationsreceive
Normalcondition:Flickering
TX GreenLamp
Serialcommunicationstransmit
Normalcondition:Flickering
Table 6-4: Ethernet to Serial Gateway Module - Controls and Indicators

Ethernet Switch Module
TheEthernetSwitchprovidesasinglepointofconnectionforEthernetcommunication.Table6-5
showsthelocationoftheindicatorsontheEthernetSwitchModule.Table6-5showsthefunction
associatedwitheachofthem.
