5. Operational Interfaces Marathon Express
Power Connections Part Number: 605914 Rev. B
AC Power Distribution Cable
ForGen5systemstheusermustfabricatethepowercablecarryingfacilitiespowertotheAC
PowerDistributionUnit(ACPDU).TheACPDUistypicallymountedontheMXsystem’sframeand
providespowertotheMXsystem’smodules.Thepin-outfortheACPDU’s200-240VACcableis
providedinTable5-3.ThepowercableconnectorsareshowninTable5-4.
AC INPUT, 200-240 VAC @ 20 A
Pin ID 2 Phase 3 Phase
X - L3
Y L2/N L2/N
Z L1 L1
G GND GND
Table 5-3: AC Power Distribution Unit Cable

Connector Located on AC Power
Distribution Unit
Connector Bagged for Facilities Power
Cable
Hubbell2425
Flangedinletconnector
250VAC,20A,3Phase,male
BrooksP/N211-0063-16
Hubbell2423
Connectorbody
250VAC,20A,3Phase,male
BrooksP/N211-0068-14
Table 5-4: AC Power Distribution Unit Connectors
