3. Installation Marathon Express
Site Requirements Part Number: 605914 Rev. B
3. Installation
TheBrooksAutomationMarathonExpresshasbeendesignedforquickandeasymountingtothe
user’sProcessModules.ThischapterprovidescompleteinstallationproceduresfortheBrooks
AutomationMarathonExpressincluding:unpacking,assembly,initialsetup,andinitialcheck-out.
Site Requirements
BeforetheBrooksAutomationMarathonExpressinstalled,thesitewheretheMXsystemwillbe
locatedmustbeproperlyprepared.Thispreparationincludesensuringthattheproperfacilities,
includingelectricalandcommunicationsconnections,areavailableandareproperlypreparedfor
connectiontotheMarathonExpress.
Floor Space and Loading
ThesitefortheMarathonExpressmustmeettheminimumspacerequirementsspecifiedin
"MechanicalSpecifications"onpage19andFigure1-3and"ExampleofServiceandExclusion
Zones-Vertical(SeeInterfaceDrawing)"onpage26toensureproperclearanceforinstallation,
operation,andservicingoftheMXsystem.NotethatthedimensionsgivenarefortheMXsystem
only.Itistheuser’sresponsibilitytoensureadequatespacearoundtheProcessModulesfor
operationandservicebasedontheirneeds.

AlldrawingswithinthismanualaregenericandmaynotreflectspecificbuildsoftheMarathonExpress.Toobtain
acompleteandcurrentsetofdrawingsanddocumentscontactBrooks.SeeContactUsformoreinformation.

