8. System Alignment Marathon Express
Teach the Robot the Integral Wafer
Buffer Station
Part Number: 605914 Rev. B
RequiredTools
l
Control/DisplayModule
l
MicroToolDummyWaferortestmaterialoftheappropriatesize
AlignmentStrategy
Fortheprocedureprovidedbelow,thefollowingconfigurationisassumed:
l
TheWaferBufferStationisStation9fortherobotinanMX800system
Procedure
Automatic Movement / Crush hazard
WheneverpowerisappliedtotheMarathonExpress,thepossibilityexistsofautomatic
movementthatcancauseseriousinjuryordeath.Thesecomponentsinclude:
l
Robot
l
Aligner
l
CoolModulePoppet
l
LoadLockModule(s)(AutoDoor,Arm,Platform)
l
AtmosphericDoors
l
VacuumSlotValves
l
IsolationValves
l
Pumps
Movingmechanismsdonothaveobstructionsensorsandcancauseseriouspersonal
injuryordeath.

DonotoperatetheMarathonExpresswithouttheprotectivecoversinplaceandall
safetyinterlocksenabled.

Donotoperatetherobotwithouttheprotectivecoversinplace.

DonotoperatetheVacuumSlotValvesorAtmosphericDoorswhenthechamberlidis
open.

AlwaysverifyproperoperationoftheCDME-Stopbuttonbeforeperforminganyteachproceduresbypressingthe
E-Stopbuttonandverifyingthatthearmisnolongerpoweredandthatwhilethebuttonisdownnomotion
commandsareaccepted.

Referto"StationCoordinateSystem"onpage108foranillustrationofstationassignments.
