Brooks Marathon Express - AC Power Distribution

5. Operational Interfaces Marathon Express
AC Power Distribution Part Number: 605914 Rev. B
AC Power Distribution
TheMarathonExpressusesanACPowerDistributionUnit(ACPDU)todistributeACpower
throughoutthetool.TheACPDUalsoprovidescircuitprotection.Table5-2showsthelocationofall
connectionsfoundontheACPDU.Table5-2liststheconnections,andshowswhichtypeof
connectorsareused.
NOTE: TheACPDUisnotintendedtosupplypowertouserinstalledmodules.
Figure 5-2: AC Power Distribution Unit - Connections
Label Description Connector Type
RECPT1 200-240VAC@20A,In NEMAL15-30P
EarthGround EarthGround Stud,M5
RECPT2 200-240VAC@20A,Outlet NEMAL6-20R
J1.1,J1.2,J1.3,J1.4J2.1,J2.2,J2.3,J2.4
200-240VAC,4Total10A(max)
Outlets(2X)
FemaleIEC320
Table 5-2: AC Power Distribution Unit - Connections
