Brooks Marathon Express - Temperature Controller

Brooks Automation 4. Subsystems
Part Number: 605914 Rev. B Transport Chamber Heating System
Figure 4-7: Cartridge Heater Styles

Temperature Controller
TheTemperatureController,showninFigure4-8,providesasingle-channeldualdisplaycontroller
forusewithDeviceNetthatoffersmanyadvancedfunctions.Thereisoneuniversalsensorinput,a
secondauxiliaryinput,andtwooutputs.Thecontrollerprovides6.5Hzsampling,variabletimebase
burstfiringoutputs,NEMA4Xfrontpaneland0.1%calibrationaccuracy.
Copyright © 2023, Brooks Automation, Inc.
95
