Brooks Automation 3. Installation
Part Number: 605914 Rev. B Power-up Sequence
MagnaTran7orLEAProbot,arecapableofEthernetcommunicationasanoption.Thetypeof
connectionsuseddependsonthegenerationofthecontrolsystemimplementedontheMXsystem.
SeeSystemBlockDiagramandthecontrolsmanualformoreinformation.
Power-up Sequence
ThefollowingproceduredescribesthestepstosafelyapplypowertotheMarathonExpresssystem
andverifythatitisreadyforoperation.
Automatic Movement / Crush hazard
WheneverpowerisappliedtotheMarathonExpress,hepossibilityexistsofautomatic
movementthatcancauseseriousinjuryordeath.Thesecomponentsinclude:
l
Robot
l
Aligner
l
CoolModulePoppet
l
LoadLockModule(s)(AutoDoor,Arm,Platform)
l
AtmosphericDoors
l
VacuumSlotValves
l
IsolationValves
l
Pumps
Movingmechanismsdonothaveobstructionsensorsandcancauseseriouspersonal
injuryordeath.

DonotoperatetheMarathonExpresswithouttheprotectivecoversinplaceandall
safetyinterlocksenabled.

Donotoperatetherobotwithouttheprotectivecoversinplace.

DonotoperatetheVacuumSlotValvesorAtmosphericDoorswhenthechamberlidis
open.

Step Action
1.
Checktoensurethatalloftheinstallationprocedurespreviouslydescribedinthischapterhavebeen
completed.
2.
OperationalSafetyandInterlockChecks:
l
EnsurethattheVCE’sdoorsareclosed.
l
EnsurethattheMarathonExpressvacuumchamberandloadlocklidsareclosedandsecured.
l
IfanE-Stopbuttonisbeingusedwiththesystem,ensurethattheE-StopJumperPlughasbeen
removedfromtheSafetyHubandtheE-StopButtonhasbeenpluggedin.
