3. Installation Marathon Express
Unpacking and Inspection Part Number: 605914 Rev. B
Package Typical Contents
Electronics
l
DCPowerSupply
l
HeaterController
l
ControllerComputer
l
Pumpcontrollers,etc.
Installation
Kit
l
CopyofATP(CertificateofPerformanceTesting)
l
Connectorforpowercable
l
Systemcables
l
MountingHardware
l
UserManuals

WhentheMarathonExpressisbeingpreparedforshipping,theouterbagiscleanedandafoilbag
isplacedaroundeachmoduleoftheMXsystem.Thefoilbagisthensealedandevacuatedandthe
systemisboltedtothecratebottombeforethecrateisclosedandboltedtogether.Tipindicators,
shockindicators,andmoistureindicatorsareattachedtoeachcrate.

Heavy Object
TheMarathonExpresscanweighasmuchas1451.5kg(3200lb).TheVacuum
CassetteElevatormodulesoftheMarathonExpressweighatleast111kg(245lb)
withoutthevacuumpumpattached.

Failuretotaketheproperprecautionsbeforemovinganyoftheseitemscouldresultin
personalinjury.

DonotattempttolifttheseMarathonExpressandVCEmoduleswithoutaforkliftora
hoist.

