Brooks Automation 12. Appendices
Part Number: 605914 Rev. B Appendix F: Packing and Shipping Instructions
Heavy Object
TheMarathonExpressweighsatleast900.0kg(1984lb)andcanweighasmuchas
1451.5kg(3200lb).

TheVacuumCassetteElevatormodulesweighatleast111kg(245lb)withoutthe
vacuumpumpattached.Therrobotdriveweighs29.5kg(65lb)3axisor21kg(46.5lb)2
axis.

Failuretotaketheproperprecautionsbeforemovinganyoftheseitemscouldresultin
personalinjury.UseaforkliftorahoisttolifttheMarathonExpress.Useaminimumof
fourpeopletomovetheMarathonExpresssystem.Useaminimumoftwopeopleto
moveanyothermodules.

Tip Hazard
TheMarathonExpressmaytipandfallwhichmaycauseseriousinjuryordeath.Ensure
thatallforceexertedontheMarathonExpressandthemodulesoftheMarathonExpress
systemwhenmovingthemisbelowtheircenterofgravity.

Failuretotaketheproperprecautionsbeforemovinganymodule,especiallywhilemovingit
intotheshippingcrate,couldresultinpersonalinjury.

DonotattempttomovetheMarathonExpresswithouttheuseofaforkliftorahoist.

ProcedureCategory
Type1Procedure:Equipmentisfullyde-energized.Referto"LaserHazards"onpage46.
RequiredToolsandEquipment
ThetoolsandmaterialsrequiredduringtheremovalandshippingoftheMarathonExpresswillvary
basedonhowitwasinstalled.Thefollowingtoolsarerecommendedasatypicaltoolset.Theuser
shouldadjustthislistasrequiredbasedontheirspecificinstallation.
