Brooks Automation 12. Appendices
Part Number: 605914 Rev. B Appendix F: Packing and Shipping Instructions
Step Action
17.
Evacuateandsealtheinnerandouterpoly-bagsusingheatsealer.
18.
Lowerthejackingcasters.
19.
Rollthesystemtotheshippingarea.
NOTE: InspectthetravelrouteoftheMarathonExpresssystem.Coverdips,thresholds,orany
unevenfloortransitionswithplates.
20.
Usingtheforklift,picktheTransportChamberuponlyenoughtocleartheshippingskid.Referto
Figure12-1forthelocationoftheforkliftchannels.

NOTE: Iftheoriginalcrateshavebecomelostordamaged,contactBrooksAutomationfor
replacements.
21.
Raisethecastersuntilthewheelsareuptotheframe.
22.
Slidetheshippingskidunderthesystem.
23.
Securethesystemtotheshippingskidusing1/2inthreadedrodthrougheachofthecasterbrackets.
Additionalblockingshouldbeaddedasrequiredtoensurethatthesystemisadequatelysecuredto
thepallet.
24.
Attachthesidesandtopofthecrate.
25.
Addtipindicators,shockindicators,moistureindicators,etc.totheoutsideofthecrateasdesiredto
verifyproperhandlingduringshipment.

