The Mix Output Menu
Spark
21-6
Using the auto set up option
Auto Set up automatically calculates the DMX offset for each spot and assigns the
appropriate addresses. If you are using only DMX spots, the Auto Setup assigns all of the
addresses from connector 2.
Keypresses Results/Comments
1. Press F1 DMX Address
2. Press F5 Auto Setup
Auto Setup automatically assigns the DMX output
address according to the number of DMX
channels required by each "patched" device.
Display message:
All addresses will be modified,
Are you sure?
3. Press F1 Yes
The DMX addresses are displayed under the spot
number.
Assigning DMX addresses to selected spots
You can assign addresses to selected spots. Using this option, you are prompted to specify
the connector assignment for each spot.
If you are using only DMX spots, spots can be assigned to either connector. If you are
using some DMX spots and High-End or S-Mix, DMX spots can only be assigned to
connector 1.
If you assign spots to connectors 1, which is the channel connectors, the spots take
precedence over channels.
Keypresses Actions/Comments
1. Press F1 DMX Address
2. Press F2 Select Spot
The system prompts for the spot number.
3. Select spots using the numeric
keypad.
A range of spots can be selected using the
key sequence [# → #].
4. Press F1 DMX 1 or F2 DMX 2
You are prompted to enter the first DMX
address.
5. Enter the DMX address in
response to the prompt.
6. Press F1 Store
If there are overlapping addresses an error message (Address is overlapping spot # Do you
want to store?) is generated. The address of the overlapped spot is displayed in red. You
must correct conflicting addresses.
