Danfoss VLT series Programming Guide

Value Denition
0 Reserved
1 Segment ID
2 Starting node
3 Ending node
4 Start action
5 End action
6 Default segment
7 Duration
8 Exit condition
9 Movement type
10 Start position
Table 7.145 Parameter IDs for PWM O Segment
Value Denition
0 Reserved
1 Segment ID
2 Starting node
3 Ending node
4 Start action
5 End action
6 Default segment
7 Duration
8 Exit condition
9 Movement type
10 Start position
11 Velocity low
12 Velocity high
13 Do compensation
14 Acceleration
15 Deceleration
16 Guide value oset
17 Timeout
Table 7.146 Parameter IDs for Friction Segment
Value Denition
0 Reserved
1 MasterPos
2 SlavePos
3 vel
4 acc
Table 7.147 Denition of Parameter Type for Basic CAM Data Points
Servo Drive Parameter Descr...
VLT
®
Integrated Servo Drive ISD
®
510 System
300 Danfoss A/S © 01/2017 All rights reserved. MG36D102
77
