CHAPTER 8
Graphic Functions: Rotation, Position, Scale
80 DL.3 Digital Light User Manual
Y Position
The Y Position parameter moves your object along the Y axis with 16-bit precision.
The midpoint of the 16-bit DMX value range, centers the image on the Y-axis. Values below the
DMX midpo
int move the object down, and values above the DMX midpoint move the object up.
Default DMX Value: 32768 (50%) = object centered in frame
Original Object 1 and Object 2
All Position DMX values = 32768 (50%)
Object 1: Y Position DMX value = 33269
Object 1: Y Position DMX value = 32255
