CHAPTER 13
Effect Mode Options Descriptions
236 DL.3 Digital Light User Manual
Texture Shift
Effect Mode parameter DMX value = 88
This effect creates offset image
elements by shifting the texture based upon selected color
values.
Modifier 1: Shifts the texture left to right
Modifier 2: Shifts the texture up to down
Modifier 3: Selects a color and scales the shift. Red and green col
or values (cyan) shift from 0
= maximum to 84 = a minimum shift. Red and blue color values (magenta) shift from 85 =
maximum to 170 = a minimum shift. Green and blue color values (yellow) shift from a 171 =
maximum to 255 = a minimum shift.
Object Effect Global Effect
Original Content
Modifier 1 parameter DMX = 24
Modifier 2 parameter DMX = 184
Modifier 3 parameter DMX = 18
