CHAPTER 17
Maintenance and Troubleshooting
DL.3 Digital Light User Manual 313
System State LEDs
Five labeled LEDs on the display panel indicate the following system activity:
Projector Lamp Life
Error
LAMP LIFE ERROR
The Lamp has exceeded its
rated life and must be
replaced now.
See Re
placing the Lamp
on page 303.
Projector Lamp Life
W
arning
LAMP LIFE WARN
The Lamp is nearing the end
of it's rated life. Replace
soon
Projector
Co
mmunication
Error
PROJ COMM ERROR
The system is unable to
communicate to the
Projector.
Check the Comm cable
co
nnections at serial port on
the back of projector and at
the fixture head card.
Make sure lamp is struck
Projector
T
emperature Fail
Error
PROJ TEMP ERROR
Projector temperature has
exceeded operational range
and has shutdown
Cool fixture and then restrike
the lamp
Projector
T
emperature
Warning
PROJ TEMP WARN
Projector is over
recommended operating
temperature
USB port
Co
mmunication
Error
USB INIT ERROR
The PC failed to initialize
USB communication with the
box card.
Contact High End Systems
Customer Supp
ort
USB port Security
Error
USB SECURE ERROR
USB failed to pass the
hardware security test.
Name Color State Description
Projector White
On Projector lamp is on
Off Projector lamp is off
Blinking Projector lamp is either cooling down or in a indeterminate state
Status Green
On (45 sec On/1.4 sec.Off) Running normal motion-control code
Blinking Board communication activity; for examp
le, during a software upload
Blinking
Slowly
320 processor card in the base housing is receiving code.
Drive Amber Blinking Hard drive activity
Server Blue Steady Internal computer is receiving power
Power Red Steady Fixture’s Motion Control system is receiving power
Issue Large Format Message Message Detail Notes
