High End Systems DL.3 - Visual Mode

CHAPTER 9
Graphic Functions: Opacity and Effects
84 DL.3 Digital Light User Manual
Visual Mode
Visual Mode options are defined using three parameters. The Visual Mode parameter has
options for enhancing and adjusting the black level and contrast of a 3-D object. Once you
choose a visual mode, two Modifier parameters adjust the selected mode.
NOTE: In most cases, you won’t see a change in the content until you adjust
the Modifier parameters for that mode.
Default DMX Value: 0 = Safe (no processing applied)
Default DMX values for Modifier 1 and Modifier 2
channels depend on the selected option.
The following table illustrates the interaction between the Visual Mode Parameter and the two
as
sociated Modifier parameters for each option.
Visual Mode Option Adjustments
DMX
Value
Name Description Modifier 1 Modifier 2
0 Safe
No visual mode processing applied to
r
endered output.
Not Used Not Used
1
Content
Optimization
Enhances image black level and
contrast
Adjusts
Back
Level
Adjusts
Contrast
2
Push
to Sepia
Fades from original image color to
sepia
Adjusts Fade
Adjusts
Satu
ration
3
Push to
R
ed
Fades from original image color to red
tones
Adjusts Fade
Adjusts
Saturation
4 Graymaker
Gradually transitions image from color
to gr
ayscale
Replaces
color with gray
Adjusts
brightness
5 Graymaker2
Converts image to grayscale
Adjusts
black level
Adjusts
contrast
6 Posterizer
Converts colors to their highest values
without bleeding or
blending
Reduces
color detail
Adjusts
Contrast
7
Color to
B/W
Fades colors to black/white with no
gr
ays
Fades color
through
B/W to
White at 100%
Not Used
8
Fire
Gradient
Maps original color intensity levels to a
r
ed-to-yellow gradient.
Fades image
to red-yellow
gr
adient
Not Used
9
Negative
Art
Reverses image color
Scales color
Subtract red to
Subtr
act Green
10
Exposure
Contr
ol
Alternate content optimization option
Expand/Contrast
Color
Adjusts
color shift
11 Invert B/W
Inverts Black and White components.
Color
remains unaffected
Sets Black
Comp
arison
Level
Sets White
Comparison
Level
12
Texture
Mix
ing
Crossfades between the current
image and a
nother graphic object
texture.
Selects the
Sour
ce Graphic
Object Texture
Controls
Crossf
ade
