CHAPTER 9
Graphic Functions: Opacity and Effects
DL.3 Digital Light User Manual 85
13
Image Scale and
Ro
tate
Scales and rotates the media file
texture applied to a 3-D object
Scales Image
Sets
Rot
ation
Angle
14 Film Roll
Scrolls the media file texture
hor
izontally or vertically
Sets Horizontal
Roll Speed
Sets Vertical
Roll Speed
15 Pixelate
Divides the image into rectangles
using the center
pixel color of each
“box” as its color
Adjusts amount of
pixelatio
n
Not Used
16 Faux LED
Divides the image into a grid of circles
to mimic
an LED wall
Varies grid from
100x100 to 10x10
Varies the
spacing and B/W
17 Faux Tile
Divides the image into square tiles
Varies grid from
1
00x100 to 10x10
Varies the
spacing and B/W
18 Fuzzifier
Creates a multi-image blurring effect
Horizontal
fuzz distance
Vertical fuzz
dist
ance
19
Drop
Shadow
Creates a scalable drop shadow
beh
ind the graphic object
Horizontal
shadow size
Vertical shadow
size
20 Zoom Blur
Zooms into a position on the image
w
ith a mult-image blurring effect
Sets horizontal
position
center
Sets vertical
position center
21
Chroma
Shif
t
Shifts the red, blue, and green
component colors
Horizontal
shift
Vertical
shift
22 ShakeNBake
Introduces a random vibration effect
Horizontal shake
Vertical
shake
23 CTO/CTB
Color temperature correction
Push to Orange Push to Blue
24 Flip
Flips layer content
Horizontal flip Vertical flip
255
Pan
and Scan
Zooms in and pans across a still
Horizontal position Vertical position
Visual Mode Option Adjustments
DMX
Value
Name Description Modifier 1 Modifier 2
