CHAPTER 16
Content Management Application (CMA)
282 DL.3 Digital Light User Manual
DL.3 and DL.2 Media Server Configuration Options
DL.3 and DL.2 fixtures include configuration options for the internal projector, the lamp, the
menu display and motion features. The six tabs are labeled Server, Fixture, Lamp, Test/Reset,
Hardware and I/O.
Server Tab
DMX Settings
Configuration Item Configuration Value Options
DMX Start Channel 1-512
DMX Source DMX512 or
Art-Net
Art-Net Subnet 0-16
Art-Net Universe 0-16
DMX Protocol
V1
V2
Sets graphic objects from 1-9
