DL.3 Digital Light User Manual 299
Chapter 17:
Maintenance and Troubleshooting
This chapter includes information on replacing parts, cleaning the fixture,
and some basic troubleshooting procedures.
The following toolset should be all you need for th
e maintenance procedures in this chapter:
•3 mm allen wrench
•5 mm allen wrench
• #2 Phillips screwdriver
•Gloves
• Protective eyewear
• Mild glass cleaner (containing no ammonia) and a soft, lint-free cotton cloth
Pan and Tilt Locking
The DL.3 fixture is equipped with mechanical pan and tilt locking latches to stabilize the fixture
for shipping or servicing. There is a single pan lock position and three tilt lock positions.
WARNING:
This fixture must be serviced by qualified personnel.
The information listed in this chapter is intended to
assist qualified personnel only.
Tilt Lock Position Options
Pan Lock
Tilt Lock
