CHAPTER 11
Global Functions
116 DL.3 Digital Light User Manual
Global Effect Mode Channels
There are five banks of Global Effect Mode parameters, each with associated Modifier
channels. All Global Effect Mode parameters have an identical list of color and visual effect
options. This lets you apply a multiple-effect combination to the composite image.
The table below describes th
e interaction between a Global Effect Mode parameter and the
three associated Modifier parameters for each option. You can find a detailed description of
each option in Chapter 13: Effect Mode Opti
ons Descriptions.
NOTE: Modifier channels for Effect Mode 1 are labeled as CMY in the Wholehog
system so you can also make use of the color picker, HSI, and other Wholehog
functions. Use the CMY parameter controls to adjust the three Effect Mode 1
Modifier parameters for both the Global and Graphic fixture types.
The default for Effect Mode 1 is set to
CMY1 as well. Other Effect Mode
Modifier channels are labeled Mod 1, Mod 2, and Mod 3.
DMX
Value
Effect Mode Name/Description
Adjustments
Modifier 1 Modifier 2 Modifier 3
0 Safe (no effects selection) NA NA NA
1 CMY (RGB inverse) Cyan Magenta Yellow
2 CMY Add, All Pixels Cyan Magenta Yellow
3 CMY Add, All Non-black Pixels Cyan Magenta Yellow
4 RGB Add, All Pixels Red Green Blue
5 RGB Add 2, All Pixels Red Green Blue
6 RGB Add, All Non-black Pixels Red Green Blue
7 RGB Swap to GBR Red to Green Green to Blue Blue to Red
8 RGB Swap to BRG Red to Blue Green to Red Blue to Green
9 Solarize 1 inverts a color if value < DMX value Red Green Blue
10 Solarize 2 inverts a color if value > DMX value Red Green Blue
11 Solarize 3 sets color to 0 if value is < DMX value Red Green Blue
12 Solarize 4 sets color to 0 if value is > DMX value Red Green Blue
13 DotP and Resample Red Green Blue
14
Color Cycle cycles colors with DMX value
cont
rolling cycle speed.
Red Green Blue
15
All or Nothing sets color values > mod value = 255
and all oth
er color values = 0
Red Green Blue
16 Solid color RGB Red Green Blue
17 RGB Invert
From Red
to C
yan
From Green to
Magenta
From Blue
to Yellow
