CHAPTER 13
Effect Mode Options Descriptions
194 DL.3 Digital Light User Manual
Digital MSpeed
Effect Mode parameter DMX value = 103
In an effort to smooth DMX data for rotation, scalin
g and position values at the Graphic Object
level, historically a crossfading algorithm has been applied to these values. Digital MSpeed
allows you to set a crossfade speed to these values to achieve smoother fading. The following
rules apply to implementing the Digital MSpeed effect:
• This effect can be applied at the Gl
obal level or the Graphic Object level but can only be
applied once at any given level. That is to say, if applied twice at the global level, only the
first (lowest numbered
• When Digital MSpeed is applied at the global level, the mspeed values are applied to all the
Graphic Objects.
• Digital MSpeed applied at the Graphic Object level takes precedence over digital mspeed
applied at the Global level. This means you can apply a global value to all the Graphic
Objects, and then override that value by assigning a different set of values on a particular
Graphic Object.
• Crossfades under digital mspeed control are linear across the fade time. All ramp, snap
combinations are set in the control system.
Modifier 1 :
applies MSpeed to rotation values. When DM
X = 0, no MSpeed is applied, and
traditional crossfading can be used. Crossfade times increase from 0 = slowest to 255 = fastest.
Modifier 2 : applies MSpeed to scaling values. When DM
X = 0, no MSpeed is applied, and
traditional crossfading can be used. Crossfade times increase from 0 = slowest to 255 = fastest.
Modifier 3 : applies MSpeed to position values. When DMX
= 0, no MSpeed is applied, and
traditional crossfading can be used. Crossfade times increase from 0 = slowest to 255 = fastest.
Object Effect Global Effect
