High End Systems DL.3 - All-In-One Control Option

CHAPTER 11
Global Functions
DL.3 Digital Light User Manual 123
All-in-One Control Option
When the Global Control parameter is set to a DMX value = 253, you can use the Global
Control Modifier parameter to control the All-in-One control option. This option helps you
visualize what the graphics engine is doing. The All-in-One option maps the media file content
of Collage and Curved Surface support effects as well as up to three effects applied to graphics
objects and displays it in a multi-quadrant grid.
These effects are accessed according to rendering hierarchy used by the graphics engine, (see
Graphics Control Hierarchy o
n page 60).
When the Global Con
trol parameter is set to the All-In-One option, you can view the individual
effects applied to each Graphic object in the Global Control Modifier parameter.
DMX
Value
Global Control Modifier Option (Glo
bal Control parameter = 253)
0
Displays each defined Graphic Object with no effects applied
As the next effect
le
vel is displayed,
each object
displays the highest
level of effect
applied to that
point.
1
Displays the first effect (if any) applied to any defined Graphic Object
2
Displays the second effect (if any) applied to any defined Graphic Object
3
Displays the third effect (if any) applied to any defined Graphic Object
4
Displays the fourth effect (if any) applied to any defined Graphic Object
5
Displays the fifth effect (if any) applied to any defined Graphic Object
6
Displays the sixth effect (if any) applied to any defined Graphic Object
7
Displays the seventh effect (if any) applied to any defined Graphic Object
8
Displays the eighth effect (if any) applied to any defined Graphic Object
9
Displays the ninth effect (if any) applied to any defined Graphic Object
