CHAPTER 13
Effect Mode Options Descriptions
190 DL.3 Digital Light User Manual
Collage Generator
Collage Generator effects let you use multiple DL.3 or DL.2 units to create virtually seamless
panoramic media projections with DMX control. You can display either stock (automated collage)
or custom content (segmented collage) and effects are available for full 360° projection. For
more information about this global effect, see
Chapter 12: Global Functions: Collage
Generator™ Effect on
page 135.
Modifier 1: Selects which type of Collage array to use
from DMX Values 1-63. A DMX value of
0 = No Collage. DMX Values of 64-255 are reserved and default to No Collage.
Modifier 2: Selects which portion of the grid a particular D
L.3 or DL.2 fixture will display. DMX
values 0-63 step through grid pattern selected by the Modifier 1 parameter. DMX values 64-255
default to the upper left corner of the grid.
Modifier 3: Adjusts edge blending betwee
n the selected portion of the image being projected
by the fixture and adjacent portions being projected by other fixtures.
Collage Generator
Effect Mode parameter DMX value = 134
The standard Co
llage Generator was the original automated collage effect and should only be
used with legacy shows.
Enhanced Collage Generator
Effect Mode parameter DMX value = 141
This automated collage effect improves the image resolution over the initial Collage Generator.
Collage Gen 3
Effect Mode parameter DMX value = 150
Collage Gen 3 e
ffect has the image resolution of the Enhanced Collage Generator effect and
further expands and improves the edge blending control.
Collage Generator Wrap
Effect Mode parameter DMX value = 145
The Collage Generator
Wrap automated effect adds right and left edge blending to create
360° panoramas.
Automated Collage Generator Options Segmented Collage Generator Options
Flat Collage 360° Wrap Flat Collage 360° Wrap
Global Effect
DMX Value
134
141 145 146 147
150 151 152 153
Object Effect Global Effect
To Next Page
