CHAPTER 13
Effect Mode Options Descriptions
DL.3 Digital Light User Manual 183
Transparent Color
These effects remove a color (or small color range) from one graphic image to reveal another
“behind” it. The removed color becomes transparent. Modifier parameters define the color you
want to select as the transparent color in terms of Red, Green and Blue values set in the
Modifier parameters.
Modifier 1: Defines the red color component from DMX val
ues of 0 = no red to 255 (100%) =
maximum red saturation.
Modifier 2: Defines the green color component from DMX values of 0 = no green to 255
(1
00%) = maximum green saturation.
Modifier 3: Defines the blue color component from DMX v
alues of 0 = no blue to 255 (100%) =
maximum blue saturation.
Transparent Color Coarse
Effect Mode parameter DMX value = 28
The Transparent Color Coarse parameter selects a color range ±40% either side of the defined
value.
Transparent Color Fine
Effect Mode parameter DMX value = 26
The Transparent Color Fine parameter selects a color range ±15% either side of the defined
value.
Transparent Color Medium
Effect Mode parameter DMX value = 27
The Transparent Color Medium parameter selects a color range ±25% either side of the defined
value.
Object Effect Global EffectObject Effect Global Effect
